Stroke of Cylinders	800mm
Origin of Cylinders	Wuxi, China
Non-load Closing Time	30s
Hydraulic System	Microcomputer automatic controlled
Rated Hydraulic Pressure	25Mpa
Main Motor Power	11KW, 2 Units
Pressurizing Motor	11KW
Main Pump	Shanghai Aviation 280 Pump, 2 Units
Pressurizing Pump	25ml/Rev  Plunger-type Pump
Platen Size	2700*1370*52mm
Separation of Platens	100mm
Main Frame Plate Thickness	30mm/22mm/12mm
Overall Dimension	3550mm*1370mm*3800mm
